Wide Product/Ratio Capability - Accommodates a variety of post-mix products including juices and lemonades with pulp, teas, and cold coffees
Large Refrigerated Cabinet - Ensures that you can safely and reliably serve the largest crowds during peak periods
Patented Mixing System - Our patented mixing system perfectly blends concentrate and water, providing consistent quality drinks without stratification, slugging, or dripping
Frost-Free Chill Compartment - Safely accommodates frozen, ambient or aseptic concentrate containers or BIB’s
LED Illuminated Graphics - Attract attention and promote a variety of drink selections
Eye-Catching Merchandiser Options - Eliminates lost sales due to ‘lights out’ and reduces life costs
Dispensing Options - Improve user experience and operation type with the choice of portion control, push to dispense or touchless
Modular Component Design - Ease of component access and replacement speeds service and maximizes up-time
Innovative Magnetic Latch - Ensures precise alignment, preventing doors from being left ajar and maintaining consistent temperatures
Enhanced Door Gasket - Engineered for superior sealing to lock in cool air and block out heat, ensuring optimal temperature control
Flow RateAdjustable water flow rate from 1-2.2 fl oz / sec
Water Connection Type0.375” (0.95 cm) SAE male flare SAE fitting on dispenser
Cup Clearance7 in (17.78 cm)
Number of Valves2
Shipping Weight125 lbs (56.7 kg)
Drink Performance and Cooling CapacityFour 5 oz drinks/min (148 mL) up to 100 drinks @ 75⁰F (24⁰C) ambient, 75⁰F (24⁰C) incoming water, and 41⁰F (5⁰C) concentrate w/o exceeding 40⁰F (4.4⁰C)
Net WeightUnit: 104 lbs (47.2 kg) Counter Weight: 136 lb (61.7 kg)
Dispenser FinishBlack plastic with stainless steel front panel
Sold-Out IndicatorNo
Water ButtonNo
Beverage CapacityTwo 0.9 gal (3.5 L) bottles
Dispense TypePush Button
Water Supply RequirementsOptimum: 50 psi (3.4 bar) @ 3 fl.oz/sec flow rate Max Pressure: 60 psi (4.1 bar)* Min Pressure: 30 psi (2.1 bar) *For water pressure exceeding the optimum supply specification, flow control set at 50 psi is recommended
